Scroll Bender BJ5
The BJ5 is a handy vice mounted scroll bender. Allows one to bend a large variety of scrolls using 1/2"w, 3/4"w, or 1"w x 1/8" thickness hot rolled flat metal strip in lengths of 12" to 36". 1/8" dia. solid round rod can also be scrolled on the BJ5.
Notice in photos how the BJ5 is marked with stops of 1" from stop A to stop L so one can easily duplicate scrolls OR if you go the maximum - scroll diameter is approx. 5 3/4".
________________________________________________________________________________________
SPECIFICATIONS:
Underside of BJ5 Scroll Bender.
Completed scroll made on BJ5.
As next 2 photos show, metal can be inserted partway or fully into slot. As shown in above photo, LESS in = little to no flat spot at the start of the scroll; FARTHER in as shown in photo below = more flat spot at the start of the scroll
Notice in photos how the BJ5 is marked with stops of 1" from stop A to stop L so one can easily duplicate scrolls OR if you go the maximum - scroll diameter is approx. 5 3/4".
________________________________________________________________________________________
SPECIFICATIONS:
- Base plate 5/16" thickness with overall diameter of 6". Tab underneath that fits in vice is 3" long x 1 1/4" high x 5/16" thickness. Height off vice is 1 3/4".
- Approx. 3 1/2 lbs., Zinc.
- Quality built product, made in USA.
Underside of BJ5 Scroll Bender.
Completed scroll made on BJ5.
As next 2 photos show, metal can be inserted partway or fully into slot. As shown in above photo, LESS in = little to no flat spot at the start of the scroll; FARTHER in as shown in photo below = more flat spot at the start of the scroll
Price each:$69.99
Item# BJ5
